26
41524-01 9-5-2001
®
Figure 10f - Attaching Fan Switch Pull
Chain Extension (Aurora/Tiffany)
AURORA AND TIFFANY LIGHT
FIXTURES
Thread the fan switch pull chain
through the grommetted hole in the
light fixture bracket. Unfasten the
extra chain looped through the hole
in the in the lower mounting cap and
attach it to the fan switch pull chain.
Repeat for light switch pull chain.
Refer to Figures 10e and 10f.
Figure 10e - Threading Fan Switch
Pull Chain through Grommet
Grommetted
Hole
Lower
Mounting Cap
Extra Chains
Hole in Lower
Mounting Cap
