Hunter Ellipse 90064 - New Construction: Suspended Installation - Final Assembly; Duct Connection and Motor Wiring; Reinstalling and Securing Motor

41722-01 09/09/2011
10
B20
F
1
2
F
•
B21
G
B22
B23
H
B24
H
B25
I
Install the wiring cover plate. Make sure all
wiring connections are inside the box or under
the wiring cover plate.
Tighten the wiring cover plate screw.
Reinstall the motor by inserting the tabs and pushing up into
position. Make sure the wires are not pinched
between the motor and the housing.
Secure the motor by tightening the 2 screws.
Connect 4” duct and vent to the outside. Tape joints.
If ducting does not t securely, an adapter may need
to be purchased.
Connect wiring from the motor to the wiring cover plate.
