Attaching the Grille
Test the motor. If the motor does not run,
check the plug connection.
Position the strain relief bracket between the
plugs as shown, and screw into place.
Remove the thumbscrews. Remove glass.
Connect wiring harness. DO NOT ALLOW THE FIXTURE TO
HANG FROM THE WIRING HARNESS.
