Secure the motor by tightening the 2 screws.
Test the motor. If the motor does not run,
check the plug connection.
Turn on the power source.
Existing Construction – accessible only from below
Remove an existing fan and check to make sure the
opening is large enough to accommodate the new
motor housing (9”x 9.75”).
Move the housing into position above the ceiling
