Hunter Ellipse 90064 - New Construction: Suspended Installation - Securing and Wiring; Installing Rails and Screws; Tightening Screws and Wire Pulling

41722-01 09/09/2011
9
B17
B15
B16
B18
A
3 Pin
2 Pin
Fan Motor
Light
Light
Green
Black
Black
Red
Red
White
Black
Black
White
White
Bare Copper
Ground
B19
Night Light
Night Light
Switch 1 (AC In)
Main Switch 1 (AC In)
Switch 2 (AC In)
*Option Fan & Main Light Together
*Option
Pull wires through the strain relief.Tighten screws.
Attach the rails onto the screws.Insert screws, leaving space between the screw
head and the joist. Screws are not provided.
Connect wires as shown.
