Hunter H39 - Page 171

Sails and Rigging
12.5
Fig.12.6
Fig.12.7
Typical Mainsheet Purchase Layout
ARCH BALE (MAINSHEET PURCHASE END TIE OFF)
BOOM BALE AND MAINSHEET BLOCK
ARCH MAINSHEET BRIDLE
MAINSHEET
MAINSHEET BOOM EXIT
MAINSHEET RUN INSIDE BOOM
MAINSHEET SHEAVE INSIDE FWD BOOM END
MAINSHEET BLOCK AT MAST STEP
MAINSHEET THRU BLOCK ORGANIZERS
MAINSHEET THROUGH SHEET STOPPERS TO WINCH
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
