Hunter H39 - Standing Rigging

Sails and Rigging
12.14
ITEM QTY FITTINGS
1 D3 2 5/16" 8 mm T-TERMINAL 308-326 15ft. 9 3/4" 4820 mm
FORK ARCO SET 10 1/2
2 V2 2 5/16" 8 mm EYE 308-306 15ft. 3" 4650 mm
EYE 308-306
3 D2 2 7/32" 6 mm T-TERMINAL 308-324 14ft. 3 3/4" 4350 mm
STD/TGLE TB 174-323-10
4 RD2 2 3/16" 5 mm FORK 308-313-01 14ft. 5 3/4" 4415 mm
STD/T TB 174-473-21
5 V1 2 5/16" 8 mm FORK ARCO SET 10 1/2 16ft. 1 1/4" 4910 mm
STD/TGLE TB 174-326-09
6 D1 2 5/16" 8 mm T-TERMINAL 308-326 15ft. 4" 4675 mm
STD/TGLE TB 174-326-09
7 RD1 2 3/16" 5 mm FORK 308-313-01 13ft. 6 1/2" 4130 mm
STD/T TB 174-473-21
8 FORESTAY 1 5/16" 8 mm FURLEX 208-15 48ft. 10 5/8" 14900 mm
OVERALL CP-CP
3. MEASURE T-TERMINALS & STEMBALLS FROM TOP OF FITTING.
1. CP = CENTER PIN; EOS = END OF STUD
2. LENGTHS DO NOT
INCLUDE SPREADER TIP LINKAGE.
HUNTER 39 FURL
STANDING RIGGING
SELDEN MAST SRIG-0055
CP-CP OR CP-EOSWIRE SIZE
