Sails and Rigging
12.15
(RD-2)
T HOOK
MARINE EYE
TURNBUCKLE
TURNBUCKLE
(FORESTAY)
(D-3)
MARINE EYE
JAW TOGGLE
JAW TOGGLE
TURNBUCKLE
(D-2)
(V-2)
(RD-1)
(D-1)
1 = LOWER
2 = INTER.
3 = UPPER
TURNBUCKLE
LOWER END
(V-1)
CABLE
MARINE EYE
MARINE EYE
SHROUD TERM
JAW TOGGLE
MARINE EYE
JAW TOGGLE
UPPER END
(MEASURED FROM THESE POINTS)
LENGTH
MARINE EYE
TURNBUCKLE
T-BOLT W/TOGGLE
V = VERTICAL
D = DIAGONAL
RD = REVERSE
DIAGONAL
1/3
2/3
NOTE: DIMENSION OF RIG LENGHTS WITH TURNBUCKLES ARE
DETERMINED WITH THE TURNBUCKLE 2/3 OPEN AS SHOWN.
1/3
2/3
CUP
STEM BALL
MARINE EYE
TURNBUCKLE
T HOOK
TURNBUCKLE
(RD-1)
FURLING
STANDARD
TURNBUCKLE
JAW TOGGLE
SHROUD TERM
SHROUD TERM
MARINE EYE
JAW TOGGLE
TOGGLE
TURNBUCKLE
INTERGRATED INTO
JIB FURLING UNIT
TYPICAL STANDING RIGGING DETAILS
Figure 12.12 Standing Rigging Details
