Sails and Rigging
12.12
ITEM QTY FITTINGS
1 D3 2 9/32" 7 mm T-TERMINAL 308-325 12 ft 10 7/8" 3935 mm
FORK 308-315-01
2 V2 2 9/32" 7 mm EYE 308-363 13 ft 5/8" 3980 mm
EYE 308-363
3 D2 2 3/16" 5 mm STEMBALL 308-552 12 ft. 11 1/4" 3945 mm
CUPS 306-572
CUPS 306-573
STD/FORK TB 174-323-05
4 RD2 2 3/16" 5 mm FORK 308-313-01 12 ft 4 1/2" 3775 mm
STD/T TB 174-473-21
5 V1 2 5/16" 8 mm FORK ARCO SET 10 1/2 21 ft 3/4" 6420 mm
STD/TGL5/8 TB 174-326-09
6 D1 2 5/16" 8 mm STEMBALL 308-555 21 ft 1/4" 6410 mm
STD/TGL5/8TB174-326-09
7 RD1 2 3/16" 5 mm FORK 308-313-01 14 ft 7 1/4" 4450 mm
STD/TGLE TB 174-323-09
8 FORESTAY 1 5/16" 8 mm FURLEX 208-15 48 ft 10 5/8" 14900 mm
OVERALL CP-CP
3. MEASURE T-TERMINALS & STEMBALLS FROM TOP OF FITTING
1. CP = CENTER PIN; EOS = END OF STUD
2. LENGTHS DO NOT
INCLUDE SPREADER TIP LINKAGE.
HUNTER 39 CONVENTIONAL
STANDING RIGGING
SRIG-0056
CP-CP OR CP-EOSWIRE SIZE
