A LPG TANK(s) LOCATED IN STRBD SWIM LOCKER
B LPG SOLENOID
C RUBBER GAS LINE HOSE (COPPER IN CERTAIN REGIONS)
D POWER LINE FROM LPG CONTROL SWITCH
E GIMBALLED STOVE
F REMOTE CONTROL SHUT-OFF LOCATED IN GALLEY FACE
G POWER FROM BATTERY SWITCH PANEL TO REMOTE SWITCH
A
F
E
C
B
D
G
**
A LPG TANK(s) LOCATED IN STRBD SWIM LOCKER
B LPG SOLENOID
C RUBBER GAS LINE HOSE (COPPER IN CERTAIN REGIONS)
D POWER LINE FROM LPG CONTROL SWITCH
E GIMBALLED STOVE
F REMOTE CONTROL SHUT-OFF LOCATED IN GALLEY FACE
G POWER FROM MAIN ELECTRIC PANEL TO REMOTE SWITCH
A
F
E
C
B
D
G
LPG (Liquied Petroleum Gas) Lines Layout
Fuel Systems
5.15
