Hunter PGP Series User Manual

®
8 9
PGP
®
Rotor
MODELS
PGS – Shrub
PGP – 4" Pop-up (10 cm)
PGH – 12" Pop-up (30 cm)
DIMENSIONS
• Overall height:
PGS – 7³⁄
8
" (19 cm)
PGP – 7³⁄
8
" (19 cm)
PGH – 17" (43 cm)
• " female inlet NPT
• Exposed diameter: 1" (4 cm)
OPERATING SPECIFICATIONS
• Discharge rate: .5 to 14.4 gpm
(0.11 to 3.27 m
3
/hr;
1.9 to 54.5 l/min)
• Radius: 22' to 52'
(6.7 to 15.9 m)
• Pressure range: 30 to 70 psi
(2.1 to 4.8 bars;
206 to 482 kPa)
• Precipitation rates:
approximately .4" (10 mm)
per hour at 50 psi
(3.4 bars; 344 kPa) for
spacings from 25' to 45'
(7.6 to 13.7 m)
• Nozzle trajectory:
standard – 25°
low-angle – 13°
OPTIONS AVAILABLE
• Factory-installed drain check valve for up to
10' (3.0 m) elevation change
• Reclaimed water cover
• Low angle nozzles
• Factory-installed nozzles
TECHNICAL INFORMATION
PRODUCT EXPLANATION
KEY TO FEATURES:
ADJ = Adjustable with no Check Valve
360 = Full-Circle with no Check Valve
ADV = Adjustable with Check Valve
36V = Full-Circle with Check Valve
ARV = Adjustable, Reclaimed Water, with Check Valve
3RV = Full-Circle, Reclaimed Water, with Check Valve
S P E C I F I C A T I O N G U I D E
EXAMPLE: PGP - ADJ - LA
MODEL
PGS = Shrub
FEATURES
ADJ, 360, ADV, 36V, ARV, 3RV
OPTIONS
XX = 12 Standard Nozzles OR:
LA = 7 Low-Angle Nozzles
01 – 12 = Factory-Installed Standard Nozzle
4 – 10 LA = Factory-Installed Low-Angle Nozzle
PGP = 4" Pop-up ADJ, 360, ADV, 36V, ARV, 3RV
PGH = 12" Pop-up ADV, 36V, ARV, 3RV
