Hunter PGP Series User Manual

®
8 9
PGP
®
Rotor
PRODUCT PERFORMANCE
Note: All precipitation rates calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Data represent test results in zero wind. Adjust for local conditions. Radius may be reduced up to 25% with adjustment screw (this may alter the
uniformity of the spray pattern). Optimum performance is shown in bold. For information on testing standards and precipitation rate calculations, see
Hunter Irrigation Products catalog.
To measure pressure at the nozzle of a PGS, PGP, PGH or any rotor sprinkler, order Hunter rotor pressure gauge kit part # 122900.
PGP Low Angle Nozzle (Gray) Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
4
30
40
50
60
22'
24'
26'
28'
1.4
1.7
1.8
2.0
0.56
0.57
0.51
0.49
0.64
0.66
0.59
0.57
5
30
40
50
60
25'
27'
28'
30'
1.6
1.9
2.1
2.3
0.49
0.50
0.52
0.49
0.57
0.58
0.60
0.57
6
30
40
50
60
27'
30'
33'
35'
2.1
2.5
2.8
3.0
0.55
0.53
0.49
0.47
0.64
0.62
0.57
0.54
7
30
40
50
60
29'
32'
35'
37'
2.8
3.1
3.5
3.8
0.64
0.58
0.55
0.53
0.74
0.67
0.64
0.62
8
30
40
50
60
31'
34'
37'
38'
3.4
3.9
4.4
4.7
0.68
0.65
0.62
0.63
0.79
0.75
0.71
0.72
9
30
40
50
60
33'
37'
40'
42'
4.3
5.0
5.6
6.1
0.76
0.70
0.67
0.67
0.88
0.81
0.78
0.77
10
40
50
60
70
38'
40'
42'
44'
6.5
7.3
8.0
8.6
0.87
0.88
0.87
0.86
1.00
1.01
1.01
0.99
P
Blank nozzle plug for turning off selected sprinklers
during repairs, maintenance, etc.
PGP Low Angle Nozzle (Gray) Performance
Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m
3
/hr l/min
4
2.1
2.8
3.4
4.1
206
275
344
413
6.7
7.3
7.9
8.5
0.32
0.39
0.41
0.45
5.3
6.4
6.8
7.6
14
14
13
12
16
17
15
14
5
2.1
2.8
3.4
4.1
206
275
344
413
7.6
8.2
8.5
9.1
0.36
0.43
0.48
0.52
6.1
7.2
7.9
8.7
13
13
13
12
14
15
15
14
6
2.1
2.8
3.4
4.1
206
275
344
413
8.2
9.1
10.1
10.7
0.48
0.57
0.64
0.68
7.9
9.5
10.6
11.4
14
14
13
12
16
16
15
14
7
2.1
2.8
3.4
4.1
206
275
344
413
8.8
9.8
10.7
11.3
0.64
0.70
0.80
0.86
10.6
11.7
13.2
14.4
16
15
14
14
19
17
16
16
8
2.1
2.8
3.4
4.1
206
275
344
413
9.4
10.4
11.3
11.6
0.77
0.89
1.00
1.07
12.9
14.8
16.7
17.8
17
16
16
16
20
19
18
18
9
2.1
2.8
3.4
4.1
206
275
344
413
10.1
11.3
12.2
12.8
0.98
1.14
1.27
1.39
16.3
18.9
21.2
23.1
19
18
17
17
22
21
20
20
10
2.8
3.4
4.1
4.8
275
344
413
482
11.6
12.2
12.8
13.4
1.48
1.66
1.82
1.95
24.6
27.6
30.3
32.6
22
22
22
22
25
26
26
25
P
Blank nozzle plug for turning off selected sprinklers
during repairs, maintenance, etc.
PGP Standard Nozzle (Red) Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
1
30
40
50
60
28'
29'
29'
30'
0.5
0.6
0.7
0.8
0.12
0.14
0.16
0.17
0.14
0.16
0.19
0.20
2
30
40
50
60
29'
30'
30'
31'
0.7
0.8
0.9
1.0
0.16
0.17
0.19
0.20
0.19
0.20
0.22
0.23
3
30
40
50
60
30'
31'
31'
32'
0.9
1.0
1.2
1.3
0.19
0.20
0.24
0.24
0.22
0.23
0.28
0.28
4
30
40
50
60
32'
33'
34'
34'
1.2
1.4
1.6
1.8
0.23
0.25
0.27
0.30
0.26
0.29
0.31
0.35
5
30
40
50
60
34'
36'
38'
38'
1.6
1.8
2.0
2.2
0.27
0.27
0.27
0.29
0.31
0.31
0.31
0.34
6
30
40
50
60
36'
38'
40'
40'
2.0
2.4
2.7
2.9
0.30
0.32
0.32
0.35
0.34
0.37
0.38
0.40
7
30
40
50
60
36'
40'
42'
42'
2.6
3.0
3.4
3.7
0.39
0.36
0.37
0.40
0.45
0.42
0.43
0.47
8
30
40
50
60
37'
40'
43'
44'
3.2
3.7
4.2
4.6
0.45
0.45
0.44
0.46
0.52
0.51
0.50
0.53
9
30
40
50
60
38'
43'
46'
47'
4.2
4.9
5.5
6.0
0.56
0.51
0.50
0.52
0.65
0.59
0.58
0.60
10
40
50
60
70
45'
48'
49'
51'
6.0
6.8
7.6
8.2
0.57
0.57
0.61
0.61
0.66
0.66
0.70
0.70
11
40
50
60
70
46'
48'
50'
51'
8.0
8.9
9.8
10.5
0.73
0.74
0.75
0.78
0.84
0.86
0.87
0.90
12
40
50
60
70
46'
48'
50'
52'
11.4
12.2
13.2
14.4
1.04
1.02
1.02
1.03
1.20
1.18
1.17
1.18
PGP Standard Nozzle (Red) Performance
Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m
3
/hr l/min
1
2.1
2.8
3.4
4.1
206
275
344
413
8.5
8.8
8.8
9.1
0.11
0.14
0.16
0.18
1.9
2.3
2.7
3.0
3
3
4
4
4
4
5
5
2
2.1
2.8
3.4
4.1
206
275
344
413
8.8
9.1
9.1
9.4
0.16
0.18
0.20
0.23
2.6
3.0
3.4
3.8
4
4
5
5
5
5
6
6
3
2.1
2.8
3.4
4.1
206
275
344
413
9.1
9.4
9.4
9.8
0.20
0.23
0.27
0.30
3.4
3.8
4.5
4.9
5
5
6
6
6
6
7
7
4
2.1
2.8
3.4
4.1
206
275
344
413
9.8
10.1
10.4
10.4
0.27
0.32
0.36
0.41
4.5
5.3
6.1
6.8
6
6
7
8
7
7
8
9
5
2.1
2.8
3.4
4.1
206
275
344
413
10.4
11.0
11.6
11.6
0.36
0.41
0.45
0.50
6.1
6.8
7.6
8.3
7
7
7
7
8
8
8
9
6
2.1
2.8
3.4
4.1
206
275
344
413
11.0
11.6
12.2
12.2
0.45
0.55
0.61
0.66
7.6
9.1
10.2
11.0
8
8
8
9
9
9
10
10
7
2.1
2.8
3.4
4.1
206
275
344
413
11.0
12.2
12.8
12.8
0.59
0.68
0.77
0.84
9.8
11.4
12.9
14.0
10
9
9
10
11
11
11
12
8
2.1
2.8
3.4
4.1
206
275
344
413
11.3
12.2
13.1
13.4
0.73
0.84
0.95
1.04
12.1
14.0
15.9
17.4
11
11
11
12
13
13
13
13
9
2.1
2.8
3.4
4.1
206
275
344
413
11.6
13.1
14.0
14.3
0.95
1.11
1.25
1.36
15.9
18.5
20.8
22.7
14
13
13
13
16
15
15
15
10
2.8
3.4
4.1
4.8
275
344
413
482
13.7
14.6
14.9
15.5
1.36
1.54
1.73
1.86
22.7
25.7
28.8
31.0
14
14
15
15
17
17
18
18
11
2.8
3.4
4.1
4.8
275
344
413
482
14.0
14.6
15.2
15.5
1.82
2.02
2.23
2.39
30.3
33.7
37.1
39.7
18
19
19
20
21
22
22
23
12
2.8
3.4
4.1
4.8
275
344
413
482
14.0
14.6
15.2
15.9
2.59
2.77
3.00
3.27
43.2
46.2
50.0
54.5
26
26
26
26
30
30
30
30

Hunter PGP Series Specifications

General

Warranty	5 years
Color	Black
Arc Adjustment	40 to 360 degrees
Pop-up Height	4"
Nozzle Trajectory	25 degrees
Inlet Size	3/4 inch
Spray Pattern	Adjustable Arc, Full Circle
