Hunter PGP Series User Manual

®
14
15
PGP
®
Rotor
Item Description Catalog No.
1
Standard Nozzle Set (12) 25˚ Trajectory 130900
2
Low Angle Nozzle set (7) 13˚ Trajectory 233200
3
Set Screw 120300
4
Protective Rubber Cover (Fits Units Manufactured After 2/93)
Black (ADJ) 269400
Black (360) 295800
Purple (ADJ) 297900
Purple (360) 298000
5
Riser Assembly ADJ 131105
360 137605
ADV, ARV 131115
36V, 3RV 137615
6
Standard Filter Screen (Black) 102600
7
Body Cap 103700
8
Riser Seal 181500
9
Spring Seat 189900
10
Retraction Spring ADJ, 360 104000
ADV, ARV, 36V, 3RV 150600
11
Pop-Up Body 100200
12
Filter Screen/Check Valve Sub-Assembly
(Black, Standard on ADV, ARV, 36V, 3RV)
142300
13
Check Valve Seal 101400
14
Retainer Clip 204900
15
Seal Replacement Kit (Includes Parts 8 & 9) 253400
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
PGP REPLACEMENT PARTS
