17
45066-01 • 03/03/10 • Hunter Fan Company
Installing the Glass Bowl
9-7. First install B10 candelabra bulbs (60
Watt Maximum) into the sockets.
9-8. Lift the glass bowl up to the light kit top
housing. Align the three tabs in the glass
bowl with the three slots in the light kit
top housing.
9-9. Rotate the glass bowl until the screw
holes in the light kit top housing line up
with the screw holes in the light kit.
9-10. Secure the glass bowl with three
decorative screws.
9 • Completing Your Installation With a Light Fixture (Continued)
Decorative
Screw
Decorative
Screw
Slot
Tab
Glass Bowl
Steps 9-8 – 9-10
To Next Page
