41797-01 • 07/06/10 • Hunter Fan Company
5 • Transmitter Installation
1. Install the 12 Volt alkaline battery (A23 or equivalent) inside the handheld transmitter, after setting the
jumpers to match the dip switches in the receiver. Refer to Figure 11.
2 Mount the remote holder over the ceiling fan’s wall switch using the existing wall plate screws. Refer to
Figure 12.
3. e transmitter can be placed on the remote holder for convenience or safekeeping.
Select your own unique code, making sure the settings match in the
transmitter and receiver.
Figure 11
Figure 12
