Husky HyPET - Page 15

Machine Layout 5
Operator Manual v 2.6 — April 2012 Introduction
Figure 1-1 Machine Orientation (Typical)
1. Clamp End 2. Non-Operator Side 3. Injection End 4. Operator Side 5. Clamp Unit and
Product Handling Area 6. Injection Unit 7. Operator Work Area
7
65
