C10/20

USER’S GUIDE

Table of Contents

Questions and Answers:

A
Albert HobbsAug 17, 2025
Why does the needle break on my Husqvarna Viking HUSKYSTAN C10 Sewing Machine?
- R
  Renee RobinsonAug 17, 2025
  Needle breaks in your Husqvarna Viking Sewing Machine can occur due to several reasons: * The needle might be damaged, so insert a new one. * Incorrect needle insertion, so ensure the flat side faces towards the back. * Wrong needle size for the fabric, so choose the correct needle. * Incorrect foot attachment, so select the correct foot. * Loose needle clamp screw, so tighten the screw. * Inappropriate presser foot for the stitch, so attach the correct presser foot. * Upper thread tension too tight, so loosen the tension.
R
Rebecca GriffinAug 20, 2025
What to do if my Husqvarna Viking Sewing Machine is skipping stitches?
- J
  Julie PerryAug 20, 2025
  Skipped stitches on your Husqvarna Viking Sewing Machine can be fixed by: * Reinserting the needle correctly, flat side towards the back. * Inserting a new needle. * Using the correct size needle for the thread. * Attaching the foot correctly. * Rethreading the machine. * Increasing the presser foot pressure.
I
Isabel WilsonAug 22, 2025
Why does the lower thread keep breaking on my Husqvarna Viking HUSKYSTAN C10?
- J
  John WrightAug 22, 2025
  To address lower thread breaks in your Husqvarna Viking Sewing Machine: * Ensure the bobbin case is correctly inserted, and the thread pulls easily. * Check the threading of both the bobbin and bobbin case. * Loosen the lower thread tension.
B
brian73Aug 26, 2025
Why is my Husqvarna Viking HUSKYSTAN C10 Sewing Machine seam gathering?
- C
  charles80Aug 26, 2025
  If your Husqvarna Viking Sewing Machine is producing seams that gather or pucker: * Select a finer needle. * Shorten the stitch length. * Loosen the thread tension.
M
Michael Harper DDSAug 28, 2025
What causes seam puckering on a Husqvarna Viking HUSKYSTAN C10?
- K
  kimberlyvaughanAug 28, 2025
  If your Husqvarna Viking Sewing Machine is experiencing seam puckering: * Loosen the thread tension. * Rethread the machine. * Choose a needle to suit the thread and fabric. * Shorten the stitch length. * Decrease the presser foot pressure.
K
Katherine BrownAug 31, 2025
Why is my Husqvarna Viking HUSKYSTAN C10 not working?
- M
  Mary GarciaAug 31, 2025
  To troubleshoot why your Husqvarna Viking Sewing Machine is not operating: * Ensure the machine is turned on. * Lower the presser foot lever. * Connect the power line plug to the electric outlet.
D
Dawn RichardsonSep 2, 2025
How to fix upper thread breaks on Husqvarna Viking HUSKYSTAN C10 Sewing Machine?
- D
  Danielle ZhangSep 2, 2025
  To resolve upper thread breaks on your Husqvarna Viking Sewing Machine: * Ensure the machine is correctly threaded. * Reduce the thread tension. * Use a larger needle if the thread is too thick. * Reinsert the needle with the flat side towards the back. * Rewind the thread onto the spool if it's wound around the spool holder pin. * Replace the needle if it is damaged.
S
Steve QuinnSep 5, 2025
How to fix loose stitches on Husqvarna Viking Sewing Machine?
- C
  Cindy HuntSep 5, 2025
  To resolve loose stitches on your Husqvarna Viking Sewing Machine: * Check the machine threading. * Thread the bobbin case correctly. * Ensure the needle size suits the fabric and thread. * Correct the thread tension.
T
Tiffany MolinaSep 8, 2025
How to fix uneven stitches on Husqvarna Viking HUSKYSTAN C10?
- J
  Jessica MorenoSep 8, 2025
  Uneven stitches and feed on your Husqvarna Viking Sewing Machine can be caused by: * Poor quality thread, so select a better quality thread. * Incorrectly threaded bobbin case, so remove and reinsert correctly. * Pulling the fabric, so avoid pulling and let the feed dogs guide it.
G
garygarciaSep 12, 2025
What to do if my Husqvarna Viking HUSKYSTAN C10 Sewing Machine jams?
- S
  Sean CurtisSep 12, 2025
  If your Husqvarna Viking Sewing Machine is jamming, remove the upper thread and bobbin case, turn the handwheel backwards and forwards by hand and remove the thread and lint.

Husqvarna Viking HUSKYSTAN C10 Specifications

General

Weight	16.5 lbs
Dimensions	18.5 x 8.5 x 12 inches
Free Arm	Yes
Needle Positions	3
Built-in Stitches	10
Stitch Width	5 mm

Summary

Machine Controls and Buttons

Operation Buttons

Details on Reverse, Auto-lock, and Needle Up/Down buttons for machine control.

Function Buttons

Explanation of Stitch Width, Stitch Length, Mirroring, and Mode Selection buttons.

Selection and Memory Buttons

Details on Memory, Clear, Arrow, Direct Pattern, and Number buttons for stitch selection.

Starting Sewing Procedures

Speed Adjustment Lever

Controls sewing speed; slide right to increase, left to decrease.

Foot Control Operation

Used to start and stop sewing; plug into connector and depress slowly to start.

Threading and Bobbin Operations

Winding the Bobbin

Step-by-step guide to winding thread onto the bobbin correctly.

Inserting the Bobbin

Procedure for correctly placing the bobbin in the bobbin case.

Threading the Upper Thread

Detailed steps for guiding the upper thread through the machine.

Using the Needle Threader

Instructions for using the automatic needle threader for efficient threading.

Stitch Adjustments and Types

Straight and Zigzag Stitch Adjustments

Adjusting needle position, stitch length, and width for straight and zigzag stitches.

Specialty Stitches

Covers Stretch, Overcasting, Blindhem, Button Sewing, and Buttonhole stitches.

Advanced Sewing Techniques

Instructions for Eyelet, Darning, Zipper Insertion, Quilting, Embroidery, and Mirroring.

Memory Functions and Pattern Programming

Programming Patterns (Models C10/C20)

Store, add, clear, and recall stitch combinations in the machine's memory.

Maintenance and Troubleshooting

Replacing the Light Bulb

Procedure for safely replacing the sewing machine's light bulb.

Routine Machine Maintenance

Cleaning the screen, surface, and hook mechanism for optimal performance.

Troubleshooting Common Problems

Guide to identifying and correcting issues like thread breaks, skipped stitches, and jams.
