Assembly
Introduction
WARNING: Read and understand the
safety chapter before you assemble the
product.
To assemble the shaft
1. Make sure that the electrical plugs are aligned.
2. Connect the ends of the shaft (A) fully.
3. Tighten the screw handle on the saw head side of
the shaft (B).
To adjust the length of the shaft
1. Loosen the screw handle at the battery housing side
of the shaft (A).
2. Adjust the shaft to an applicable length.
3. Tighten the screw handle (B).
To adjust the harness
Always use the harness when you operate the product.
The harness gives maximum control during operation of
the product. The harness decreases the risk of tiredness
in your arms and back.
1. Put on the harness.
2. Attach the product to the harness support hook.
3. Adjust the length of the harness until the support
hook is roughly level with your right hip.
Operation
To do a function check before you use
the product
1. Examine the air intake for dirt and damage. Remove
grass and leaves from the product with a brush.
2. Make sure that the product operates correctly.
3. Tighten all nuts and screws.
4. Make sure that the saw head is attached correctly.
5. Examine the saw head for damages, for example,
cracks. Replace the saw head if it is damaged.
6. Make sure that the covers are not damaged and that
the covers are attached correctly.
To connect the battery charger
1. Connect the battery charger to the voltage and
frequency that is specified on the rating plate.
12 707 - 008 - 06.04.2021
