DM 220
EN Operator's manual 2-26
DE Bedienungsanweisung 27-52
FR Manuel d'utilisation 53-78
NL Gebruiksaanwijzing 79-104

Table of Contents

Questions and Answers

  • T
    Timothy BlackAug 1, 2025
    What to do if my Husqvarna DM 220 stops working?
    • C
      cwilsonAug 1, 2025
      The Husqvarna Drill may stop due to several reasons. First, check the current source for any faults, as the Elgard™ function might have disconnected the current. Second, if the drill bit is blocked, try turning it right and left with a wrench and carefully remove the drill from the hole. Third, the motor may be overloaded due to a high load; ensure the drill bit can turn easily. Finally, if there is a red light on the PRCD, push the "RESET" button. If the PRCD disconnects the current again, speak to an approved Husqvarna service center.
  • K
    Kelly BurnettAug 8, 2025
    What to do if material collects around the Husqvarna Drill hole?
    • J
      Jesse JohnsonAug 8, 2025
      If unwanted material collects around the hole during Husqvarna Drill operation, the water pressure may be too low. Increase the water pressure. Refer to Technical data on page 22.
  • V
    veronicaortegaAug 16, 2025
    Why are diamond segments pulling out of my Husqvarna Drill bit?
    • M
      Michael GeorgeAug 16, 2025
      If the diamond segments on the drill bit of your Husqvarna Drill are pulled out of their bond, it indicates excessive vibration during operation. Use correct load when you operate the product.
  • J
    Jared MunozAug 23, 2025
    Why is my Husqvarna Drill leaking gear oil?
    • W
      wclarkAug 23, 2025
      If there is a leakage of gear oil from your Husqvarna Drill, the seals are worn out and must be replaced. Speak to an approved Husqvarna service center.

Summary

Product overview

Safety definitions

General power tool safety warnings

Covers general hazards and essential safe operation practices for power tools.

Work area safety

Details maintaining a safe, clean, and well-lit work environment.

Electrical safety

Outlines crucial precautions to prevent electric shock.

Personal safety

Power tool use and care

Drill safety warnings

Safety instructions for all handheld operations

Diamond drill safety warnings

General safety instructions

Safety instructions for operation

Personal protective equipment

Safety devices on the product

Motor overload protection, Elgard

Friction clutch

PRCD

Safety instructions for maintenance

Operation

To do before you operate the product

Pre-operation checks and preparations required before using the drill.

To use the product with a drill stand

To prepare the product for operation with a drill stand

To use the product handheld

To set the auxiliary handle in an applicable position

To prepare the product for dry drilling

To prepare the product for wet drilling

To prepare the product for inverted drilling

To change gear

To drill a hole at a specified angle

To do a configuration of the electronic level indicator

To start the product

To drill a start hole with the Smartstart function

To operate the product

To stop the product

To reset the motor overload protection

To replace the drill bit

Maintenance

Maintenance schedule

Table detailing maintenance tasks and recommended intervals for operator and service.

To do maintenance of the diamond drill bit

To replace the gear oil

To examine the carbon brushes

Troubleshooting

Troubleshooting schedule

Table listing common problems, possible causes, and their solutions.

Transportation and storage

Technical data

Service

Approved service center

Husqvarna DM 220 Specifications

General IconGeneral
Voltage230 V
Rated Input Power710 W
Spindle Speed Gear 20-2800 rpm
Power SourceElectric
No-Load Speed0-2800 rpm
