Husqvarna FC 250 2023 User Manual

11 SERVICE WORK ON THE CHASSIS
48
11.1 Raising the motorcycle with a lift stand
Note
Material damage The vehicle may be damaged by incorrect procedure when parking.
Significant damage may be caused if the vehicle rolls away or falls over.
The components for parking the vehicle are designed only for the weight of the vehicle.
– Park the vehicle on a firm and level surface.
– Ensure that nobody sits on the vehicle when the vehicle is parked on a stand.
401942-01
– Raise the motorcycle at the frame underneath the engine.
Lift stand (81329955100)
Neither wheel is in contact with the ground.
– Secure the motorcycle against falling over.
11.2 Removing the motorcycle from the lift stand
Note
Material damage The vehicle may be damaged by incorrect procedure when parking.
Significant damage may be caused if the vehicle rolls away or falls over.
The components for parking the vehicle are designed only for the weight of the vehicle.
– Park the vehicle on a firm and level surface.
– Ensure that nobody sits on the vehicle when the vehicle is parked on a stand.
H02629-10
– Remove the motorcycle from the lift stand.
– Remove the lift stand.
–
To park the motorcycle, insert plug-in stand
1
into the left
side of the wheel spindle.
Plug-in stand (A46029094000)
Info
The plug-in stand is included.
Remove the plug-in stand before riding.

Husqvarna FC 250 2023 Specifications

General

Engine Type	Single cylinder, 4-stroke
Bore x Stroke	78 mm x 52.3 mm
Compression Ratio	14.4:1
Starter	Electric starter
Transmission	5-speed
Cooling	Liquid cooled
Front Suspension	WP XACT-USD, Ø 48 mm
Rear Suspension	WP XACT Monoshock with linkage
Front Tire	80/100-21
Rear Tire	100/90-19
Front Wheel	1.60 x 21"
Rear Wheel	2.15 x 19"
Ground Clearance	370 mm
Displacement	249.9 cc
Fuel Capacity	7.2 liters
Clutch	Wet, multi-disc, Brembo hydraulics
Frame	Central double-cradle type 25CrMo4 steel
Front Brake	Disc brake, 260 mm
Rear Brake	Disc brake, 220 mm
Wheelbase	1485 mm
