Husqvarna K1270 II User Manual (English)

Other manuals for Husqvarna K1270 II

Questions and Answers:

D
David ContrerasAug 21, 2025
Why my Husqvarna K1270 II Cutter does not start?
- B
  Brooke WilliamsAug 21, 2025
  If your Husqvarna Cutter doesn't start, there are several potential causes. First, ensure the stop switch is in the left position. If that's not the issue, check if the fuel tank is empty and fill it if necessary. A defective spark plug could also be the culprit, so consider replacing it. If the start procedure was done incorrectly, refer to the manual pages 21 and 22 for cold and warm engine start instructions. If none of these steps work, the clutch may be defective, and you should speak to your service agent.
M
Martin WrightAug 22, 2025
Why Husqvarna K1270 II won't start?
- K
  Kelly HowellAug 22, 2025
  Your Husqvarna Cutter might not start due to several reasons. Ensure the stop switch is in the left position. Check if there is fuel in the fuel tank and fill it if needed. A defective spark plug can also prevent starting, so replace it. If the start procedure was done incorrectly, refer to the manual on how to start the product with a cold or warm engine.
L
linda41Aug 25, 2025
What to do if my Husqvarna K1270 II Cutter has no power?
- J
  Jeremy LarsonAug 25, 2025
  If your Husqvarna Cutter lacks power when you throttle up, the air filter might be clogged, so examine and replace it if needed. Also, a clogged fuel filter could be the reason, and it should be replaced. If these steps don't resolve the issue, the fuel tank flow may be blocked, and you should speak to your service agent.
V
Vincent TerryAug 27, 2025
How to fix a Husqvarna Cutter when the engine does not start?
- P
  Philip CalderonAug 27, 2025
  If the Husqvarna Cutter engine doesn't start, several issues could be the cause. Start by ensuring the switch is in the left position (not OFF). If that's not the issue, check the spark plug. If the spark plug electrodes are wet, dry them. If there's carbon, remove it or replace the spark plug. Also, inspect the ignition cable for damage; if damaged, replace the spark plug. Ensure the space between the spark plug electrodes is correctly adjusted to 0.5 mm using Champion RCJ 6Y/NGK BPMR 7A. Other potential problems include a defective coil insulation (replace it), damaged or broken cable trunks (repair or replace them), incorrect distance between the rotor and coil (adjust to 0.3 mm), a defective switch (replace it), or a grounded primary wire (repair or replace it).
S
Stacy DunnAug 28, 2025
What to do if Husqvarna K1270 II Cutter has no power when throttling up?
- G
  Glenn RobinsonAug 28, 2025
  If your Husqvarna Cutter lacks power when throttling up, the air filter or fuel filter might be clogged. Examine and replace them if necessary. If the fuel tank flow is blocked, speak to your service agent.
E
efordAug 29, 2025
Why does Husqvarna K1270 II engine decrease in power?
- C
  Claire JonesAug 29, 2025
  If your Husqvarna Cutter engine loses power or speed, the air filter may be clogged. Examine the air filter.
S
stevensdevonAug 31, 2025
What to do if Husqvarna Cutter blade doesn't rotate?
- D
  David LeAug 31, 2025
  If the cutting blade on your Husqvarna Cutter isn't rotating when you throttle up, the belt might be too loose or defective; tighten or replace it. Also, ensure the cutting blade is correctly installed. If neither of these solutions works, the clutch may be defective; in this case, speak to your service agent.
C
Chelsea FreySep 2, 2025
Why is my Husqvarna K1270 II Cutter overheating?
- B
  Bobby ValenzuelaSep 2, 2025
  If your Husqvarna Cutter is overheating, start by cleaning the air intake and cylinder flanges, as they might be blocked. Check the drive belt tension and adjust if it's insufficient. Always cut at full throttle. If the issue persists, examine the clutch and speak to your service agent, as it may be defective.
S
Stacey SmithSep 4, 2025
How to stop Husqvarna K1270 II blade rotating at idle?
- J
  joshuavillaSep 4, 2025
  If the cutting blade on your Husqvarna Cutter rotates at idle speed, the idle speed might be too high, so adjust it. If the problem continues, the clutch may be defective, and you should speak to your service agent.
J
Jonathan MillerSep 5, 2025
What to do if there is much dust using Husqvarna K1270 II Cutter?
- S
  scott94Sep 5, 2025
  If you notice excessive dust during the operation of your Husqvarna Cutter, the water supply or pressure may be insufficient. Check the water supply to the product. Refer to page 35 to check the water supply system.

Husqvarna K1270 II Specifications

General

Power output	5.8 kW
Idling speed	2700 rpm
Max. power speed	9000 rpm
Spark plug	NGK BPMR7A
Sound pressure level at operator's ear	104 dB(A)
Max cutting depth	145 mm
Engine	2-stroke
Blade diameter	400 mm
Weight	13.7 kg

Summary

Introduction and Product Information

Owner Responsibility

Defines owner's duties regarding product safety and knowledge.

Product Description and Intended Use

Overview of the power cutters and their specific applications.

California Proposition 65 Warning

States warnings about chemicals causing cancer or reproductive harm.

Product Overviews and Identification

K1270 II Component Overview

Visual identification of components for the K1270 II model.

K1270 II Rail Component Overview

Visual identification of components for the K1270 II Rail model.

Product Symbols and Decals

Explains warning symbols and provides details on decals and plates.

Component Identification Details

Information on start instructions, cutting equipment, and type plate.

Safety

Safety Definitions and General Instructions

Explains safety symbols and provides essential operational safety guidelines.

Operation and Work Area Safety

Details safety measures for product operation and the surrounding work environment.

Vibration, Exhaust Fumes, and Dust Safety

Addresses risks from vibrations, exhaust fumes, and dust inhalation.

Personal Protective Equipment (PPE)

Specifies required PPE for safe operation.

Safety Devices and Checks

Emphasizes inspection of safety devices like throttle lockout and stop switch.

Component Safety Precautions

Focuses on safety aspects of blade guard, muffler, and fuel handling.

Maintenance and Assembly

Maintenance Safety

General safety rules to follow before performing maintenance.

Cutting Blade Assembly and Types

Warnings and guidelines for assembling cutting blades, including applicable types.

Bonded Abrasive Blades: Use and Examination

Describes bonded abrasive blades, their examination, and vibration.

Diamond Blades: Use, Sharpening, and Examination

Details on diamond blades, sharpening, wet/dry use, and spindle/flange inspection.

Blade Installation and Cutting Head Reversal

Procedures for blade installation, rotation checks, and reversing the cutting head.

Operation and Cutting Techniques

Kickback Hazards and Prevention

Explains kickback phenomena, reactive force, and avoidance strategies.

Cutting Techniques and Safety

Covers pinching kickback, pipe cutting, preventing kickback, and basic working methods.

Dust Reduction

Guides for minimizing dust during operation.

Fuel and Starting Procedures

Fuel and Two-Stroke Oil Management

Guidelines for selecting, mixing fuel and oil, and safe fueling.

Starting the Product (Cold and Warm Engine)

Step-by-step guides for starting cold and warm engines.

Stopping the Product

Instructions on how to safely shut down the product.

Rail Cutting

Rail Cutting Precautions and Preparation

Warnings for rail fixture use and steps to prepare the cutting guide.

Installing and Using the Rail Fixture

Procedures for attaching and using the rail fixture for accurate rail cutting.

Maintenance Schedule and Procedures

Maintenance Schedule

Overview of daily, weekly, and monthly maintenance tasks.

Cleaning and Spark Plug Inspection

Procedures for cleaning external parts, air intake, and inspecting the spark plug.

Drive Belt and Starter Housing Maintenance

Instructions for replacing the drive belt and removing/installing the starter housing.

Spring, Carburetor, and Filter Maintenance

Guides for recoil spring, carburetor, fuel system, and filter maintenance.

Troubleshooting and Support

Troubleshooting Common Issues

Lists common problems, their causes, and possible solutions.

Water Supply System Check

Steps to inspect nozzles and filter for the water delivery system.

Transportation, Storage, and Disposal

Guidelines for safely transporting, storing, and disposing of the product.

Technical Data and Warranty

Technical Specifications

Specifications for K1270 II and K1270 II Rail models.

Noise and Vibration Declaration

Declared values for noise and vibration based on laboratory testing.

Warranty Information

Details emission warranty, coverage, claims, and service locations.
