Husqvarna SMR 449 2011 I.E. User Manual

D.4
TC 449 2011/2012 I.E.
TE 449 - 511 2011/2012 I.E.
TXC 449 - 511 2011/2012 I.E.
SMR 449 2011 I.E.
SMR 511 2011/2012 I.E.
H006112
2
H006110
2
H006109
1
H006111
1
SETTINGS AND ADJUSTMENTS
Workshop Manual Ed. 03-2012
Saddle removal
Turn pin (1) counter clockwise, and remove saddle (2) from central retaining screw.
Side panel removal
- Remove the saddle as described in the relevant paragraph.
- Left-hand side panel:
Loosen the four screws (1) using an 8 mm wrench, and remove the side
panel (2).
