Husqvarna TC 238T User Manual

Full lever/extension
Support brackets
Offset strut
Latch extension spring
Grass catcher presence lever
5/16 x 18 x 1.5" Carriage bolts
5/16 x 18 Lock nuts
Full lever shroud
10-24 x 1/2 Buttonhead screw
Cross brace
Grass catcher handle
Clevis pin
Clip
3/8 x 16 x 3/4 Screw
10-24 Nut
Front frame
Pivot
3/8 x 16 x 1" Nut
3/8 x 16 x 1" Carriage bolts
To assemble the grass catcher
1. Unfold the bag and put it right side up.
2. Remove the 2 screws and the 2 nuts (A) from the
front of the top frame.
A
3. Put the grass catcher on the side.
2010 - 003 - 10.04.2023
11

Husqvarna TC 238T Specifications

General

Engine Manufacturer	Briggs & Stratton
Engine Name	Intek
Cylinder	1
Fuel Type	Gasoline
Transmission Type	Hydrostatic
Net Power RPM	2600 rpm
Oil Filter	Yes
Transmission Manufacturer	Tuff Torq
Transmission Model	K46
Cutting Height Steps	6
Blade Engagement	Electric
Blades	2
Nose Wheel	No
Collector	Included
Mulch Kit	Available as accessory
Cutting Width	38 in
Cutting Height Max	4 in
Fuel Tank Volume	2.5 gal (US)
Tire Size Front	15x6-6"
Tire Size Rear	20 x 10.00-8
Wheelbase	48 in
Turning Radius	0 cm
Uncut Circle	0 cm
Power Output	6.5 kW (8.7 hp)
