11 SERVICE WORK ON THE CHASSIS
68
F00108-10
(TX 300)
– Mount the front of the seat on the collar bushing of the
fuel tank and the rear in the bracket.
– Push the seat forward.
– Make sure that the seat is correctly locked in.
–
Mount and tighten screw
1
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
Finishing work
– Install the air filter box cover. ( p. 69)
11.22 Removing the air filter box cover
K00901-10
(TC 250)
–
Pull off the air filter box cover sideways in areas
A
,
B
and
C
, and remove toward the front.
K00908-10
(TX 300)
–
Pull off the air filter box cover sideways in areas
A
,
B
and
C
, and remove toward the front.

Husqvarna TC 250 Specifications

General

Displacement	249 cc
Starter	Kickstarter
Front Brake Dimensions	260 mm
Rear Brake Dimensions	220 mm
Engine Type	Single-cylinder, 2-stroke
Bore x Stroke	66.4 mm x 72 mm
Front Brake	Disc brake
Rear Brake	Disc brake
Fuel Tank Capacity	7.5 liters
Rear Suspension	WP XACT shock
