14 WHEELS, TIRES
102
Info
Do not operate the foot brake lever when the rear
wheel is removed.
H03002-10
–
Remove spacers
4
.
14.4 Installing the rear wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
H03001-10
Main work
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change the rear wheel bearing.
–
Clean and grease shaft seal rings
1
and contact
surfaces
A
of the spacers.
Long-life grease ( p. 159)
– Insert the spacers.
H03735-10
– Clean and grease the wheel spindle.
Long-life grease ( p. 159)
–
Position rear wheel and insert wheel spindle
2
.
The brake linings are correctly positioned.
– Mount the chain.
