Page 17
SECTION 5
ELECTRICAL
CONNECTIONS
Electrical power connections are made at the left-hand end of the case, behind the removable base
panel. The left-hand end of the case is determined when facing the discharge honeycomb.
REMOTE MODELS
All electrical connections for remote models will be made in the junction box located behind the
removable base panel, at the left-hand end of the case.
SELF CONTAINED MODELS
All electrical connections for self-contained models will be made in the control panel of the case. All
electrical circuits have been terminated inside the control panel and “pig-tailed” wiring provided for
ease of connecting field wiring. See appropriate wiring diagram in this section.
CAUTION:
THE FIXTURE MUST BE ELECTRICALLY GROUNDED.
ALL WIRING AND CONNECTIONS MUST COMPLY
WITH N.E.C., C.S.A. AND LOCAL CODES.
