Hussmann Q2SSM4S - Control & Sensor Configuration

3-6 start up / opEratIon
P/N 0562873_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
Power Supply - 1000W 24VDC
Control with display
Relay
Switch MTR Start
SGL Pole SQ
HUSSMANN_GDF_2.1 SHEET SIZE D
THIRD
ANGLE
PROJECTION
TOLERANCES ARE:
DECIMALS .XX
u .03, .XXX u .010
ANGLES
u 2 v
Error: No reference Error:
N
Temperature Sensor
(Black Lead)
Defrost Termination
Sensor (Yellow Lead)
Defrost
Termination Sensor
(Yellow Lead)
Defrost
Termination Sensor
1.5m
Temperature Sensor
3.5m
Control & Sensor Conguration
