Hussmann Q2SSM4S - Replacement Parts List

P/N 0562873_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
5-2 sErvIcE — tEchnIcal Data
Replacement Parts List
Standard
Parts Description
Part Number Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
Black End Trim
1750301121 X X X X X X X X X X Table 1.1
End Plexiglass Q1
0558332 X X X
End Plexiglass Q2
0558709 X X X X
End Plexiglass Q3
0558710 X X X
Caster
175018505 X X X X X X X X X X
Drain Trap
18S279 X X X X X X X X X X
Cover Drain
0301266 X X X X X X X X X X
Thermometer (solar)
0517730 X X X X X X X X X X
Black bumper
1H19068700 X X X X X X X X X X
Black bumper end cap
1H19070700 X X X X X X X X X X
Aluminum bumper base
175035002 X X X X X X X X X X
Black Telescopic shelf
0514078 X X X X X X X X X X
Front plexiglass 7" 2 ft
3081334 X
Front plexiglass 11.5" 2 ft
3081333 X
Front plexiglass for shelf 2 ft
3081310 X
Front plexiglass 8.5" 4 ft
0555039 X X X
Front plexiglass 11" 4 ft
0555059 X X X
Front plexiglass for shelf 4 ft
0555042 X X X X
Front plexiglass 11" 6 ft
0552793 X X X
Front plexiglass 8.5" 6 ft
0555336 X X
Front plexiglass 4.937" 6ft
3027214 X
Front plexiglass for shelf 3 ft
0557223 X X
Front plexiglass 11" 8 ft
0555419 X X X
Front plexiglass 8.5" 8 ft
0555420 X X
Front plexiglass 4.937" 8ft
3027215 X
Binding screw #8-32 1/4
300030604 X X X X X X X X X X
Post binding #8-32 1/2
175010369 X X X X X X X X X X
Led light 24" 3000K
3004886 X
Led light 48" 3000K
3004895 X X X X
Led light 36" 3000K
0523750 X X
Clip for led light
0523762 X X X X X X
Switch led light
125010307 X X X X X X X X X X
Power supply 1000w 24VDC
3079207 X X X X X X X X X X
Fuse 15 amp
125018604 X X X X X X X X X X
Fuse holder
125018605 X X X X X X X X X X
Refrigeration
Description
Part Number Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
Distributor (Sporlan 1620)
1H18877500 X X X X X X X X X X Table 1.2
Expansion valve (Sporlan EGDE-1/5-C)
3031922 X
Expansion valve (Danfoss 068U2138)
225013403 X X X
Expansion valve (Danfoss 068U2137)
225013356 X
Expansion valve (Danfoss 068U2139)
0460972 X X X
Expansion valve (Danfoss 068U3367)
0460973 X
Heat exchanger
225013305A X
Heat exchanger
00008480 X X X X X X X X X
Evaporator 2 ft
3027787500 X
Evaporator 4 ft
0498770 X X X
Evaporator 6 ft
050033700 X X X
Evaporator 8 ft
0500335 X X X
Plastic collar fan
0409510 X X X X X X X X X X
Aluminum fan blade (6.70", 15°)
0428111 X X X X
Aluminum fan blade (6.70", 20°)
0409511 X X
Aluminum fan blade (6.70", 25°)
0409512 X X X X
Evaporator fan motor (115V, 4W)
0477653 X X X X X X X X X X
Bracket fan motor
0552827 X X X X X X X X X X
Sight glass (Sporlan SA-13)
225010075 X X X X X X X X X X
Drier (Sporlan C-163-S)
1701595 X X X X X X X X X X
Condensing unit (M6JM-H028-IAA-025)
3089783500 X
Condensing unit (M4FH-0050-CAA-212)
225030081 X
Condensing unit (M4FF-0080-IAV-212)
1H28154500 X
Condensing unit (M4FF-0075-CAV-212)
1H28155500 X X
Condensing unit (FJAF-B100-CFV-021)
1H28147500 X X
Condensing unit (M4FF-0056-IAA-041)
1H28153500 X X
Condensing unit (M4EH-0049-CAA-020)
1H28199500 X
Condensing unit main switch
E205705 X X X X X X X X X X
Refrigeration Description
PartNumber Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
Distributor(Sporlan1620)
1H18877500 X X X X X X X X X X
Table1.1
Heatexchanger
225013305A X
Heatexchanger
00008480 X X X X X X X X X
Evaporator2ft
3027787500 X
Evaporator4ft
0498770 X X X
Evaporator6ft
050033700 X X X
Evaporator8ft
0500335 X X X
Plasticcollarfan
0409510 X X X X X X X X X X
Aluminumfanblade(6.70",15°)
0428111 X X X X
Aluminumfanblade(6.70",20°)
0409511 X X
Aluminumfanblade(6.70",25°)
0409512 X X
XX
Evaporatorfanmotor(115V,4W)
0477653 X X X X X X X X X X
Bracketfanmotor
0552827 X X X X X X X X X X
Sightglass(SporlanSA‐13)
225010075
X X X X X X X X X X
Drier(SporlanC‐163‐S)
1701595 X X X X X X X X X X
Condensingunitmainswitch
E205705 X X X X X X X X X X
RefrigerationR404A Description
PartNumber Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
Expansionvalve(Danfoss068U2138)
225013403 X X X
Expansionvalve(Danfoss068U2137)
225013356 X
Expansionvalve(Danfoss068U2139)
0460972 X X X
Expansionvalve(Danfoss068U3367)
0460973 X
Condensingunit(M4FH‐0050‐CAA‐212)
225030081 X
Condensingunit(M4FF‐0080‐IAV‐212)
1H28154500 X
Condensingunit(M4FF‐0075‐CAV‐212)
1H28155500 X X
Condensingunit(FJAF‐B100‐CFV‐021)
1H28147500
XX
Condensingunit(M4FF‐0056‐IAA‐041)
1H28153500 X X
Condensingunit(M4EH‐0049‐CAA‐020)
1H28199500
X
RefrigerationR448A Description
PartNumber Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
ExpansionvalveR448(SporlanEGDE‐1/4‐C)
3031926 X
Expansion Valve R448 EDGE-1/2-C)
3031934 X X X
Expansionvalve(SporlanEGDE‐1/5‐C)
3031922 X
Condensingunit(M6JM‐H028‐IAA‐025)
3089783500 X
CondensingunitR448(M6EM‐H046‐CAA‐020)
3062007500 X
CondensingunitR448(M6GP‐H064‐CAA‐177)
3087874500 X X X
CondensingunitR448(M6GP‐H090‐CAV‐212)
3082678500 X X X
CondensingunitR448(M6KP‐0127‐CFV‐020)
3082674500
XX
X X X
X X
