HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Q1, Q2, Q3 Merchandisers
P/N 0562873_M 5-3
Replacement Parts List Continued
Heaters and Harnesses
Description
Part Number Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
Evap Pan 1000W-120 1H95134550 X X X
Table 1.3
Evap Pan 1500W-240V 1H95137550 X X X X X
Evap Pan 1500W-120 1H95136550 X X
Power cord L5-30P 0557077 X X X X X
Power cord L14-30P 0557599 X X X X X
Canopy Led harness 0523772 X X X X X X X X X X
Shelf led harness (male) 523768 X X X X X X X
Shelf led harness (female) 1H26295550 X X X X X X X
Sheet Metal Replacement Parts Painted
Description
Part Number Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
Shelf 12" X 23.5"
3081315 X Table 1.4
Shelf 12" X 48"
0555047 X X X X
Shelf 12" X 36"
0555320 X X
Shelf 18" X 48"
0557068 X X
Shelf 18" X 36"
0556463 X
Rear top cover grill 2 ft
3081319 X
Rear top cover grill 4 ft
0555105 X X X
Rear top cover grill 6 ft
0561682 X X X
Rear top cover grill 8 ft
0555415 X X X
Front bottom grill 4 ft
0555079 X X X
Front bottom grill 6 ft
0555343 X X X
Front bottom grill 8 ft
0555430 X X X
Bracket mount rack 24"
3081317 X
Bracket mount rack 48"
0555050 X X X X X X
Bracket mount rack 36"
0552788 X X X
Air deck pan (top) 2 ft
3081325 X
Air deck pan (bottom) 2 ft
3081326 X
Air deck pan (top)
0552840 X X X X X X X X X
Air deck pan (bottom)
0552846 X X X X X X X X X
Back panel Q1 4ft
0558335 X X
Back panel Q1 6ft RH (thermometer)
0558629 X
Back panel Q1 6ft LH (sensor)
0558630 X
Back panel Q1 8ft RH
0558637 X
Back panel Q2 2ft
3081341 X
Back panel Q2 4 ft
0555064 X X
Back panel Q2 6 ft RH (thermometer)
0555334 X
Back panel Q2 6 ft LH (sensor)
0555335 X
Back panel Q2 8 ft RH
0555410 X
Back panel Q3 4 ft
0557081 X X
Back panel Q3 6 ft RH (thermometer)
0552860 X
Back panel Q3 6 ft LH (sensor)
0552863 X
Back panel Q3 8 ft RH
0557173 X
Side panel chimney Q1 RH
0558333 X X X
Side panel chimney Q1 LH
0558334 X X X
Side panel chimney Q2 RH
0555102 X X X X
Side panel chimney Q2 LH
0555103 X X X X
Bottom panel chimney 4 ft
0555100 X X X
Back panel chimney Q1 4ft
0558348 X
Back panel chimney Q1 6ft
0558627 X
Back panel chimney Q1 8ft
0558638 X
Bottom panel chimney Q2 2 ft
3081277 X
Back panel chimney Q2 2 ft
3081324 X
Back panel chimney Q2 4 ft
0555104 X
Bottom panel chimney 6 ft
0555346 X X X
Back panel chimney Q2 6 ft
0555349 X
Bottom panel chimney 8 ft
0555416 X X X
Back panel chimney Q2 8 ft
0555422 X
Side panel chimney Q3 RH
0557078 X X X
Side panel chimney Q3 LH
0557079 X X X
Back panel chimney Q3 4 ft
0557080 X
Back panel chimney Q3 6 ft
0556853 X
Back panel chimney Q3 8 ft
0557175 X
Controller Parts
Description
Part Number Q1SSM4S Q1SSM6S Q1SSM8S Q2SSM2S Q2SSM4S Q2SSM6S Q2SSM8S Q3SSM4S Q3SSM6S Q3SSM8S
PRE-PROGRAMMED CONTROL Q1 3060985 X X Table 1.5
PRE-PROGRAMMED CONTROL Q1 3060986 X
PRE-PROGRAMMED CONTROL Q2 3081701 X
PRE-PROGRAMMED CONTROL Q2 3060987 X
PRE-PROGRAMMED CONTROL Q2 3060988 X X
PRE-PROGRAMMED CONTROL Q3 3060989 X
PRE-PROGRAMMED CONTROL Q3 3060990 X X
Compressor relay (120V)
0459304 X X X X X
Compressor relay (220V)
1804241 X X X X X
