P/N 0562873_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
5-4 sErvIcE — tEchnIcal Data
Q2SSM2S
Case Length (Note: includes one pair of ends)
Optional End Bumpers (One pair)
Maximum O/S dimension of case back to front
Waste Outlet Q2SSM2S
LH end of case (from outside of End Assembly) 10.05" (25.52 cm)
to center of waste outlet
25" (63.5 cm)
1" (2.54 cm) per Bumper
48.35" (123 cm)
Dimensions shown as inches
