HUSTLER Super 104 - Engine Oil and Filter; Fuel Evaporation System Filter

REV B 6-6 117364
NOTE:
1. Spring length after tensioning new belt. Measured from outside of hook to outside of hook with deck set at 3¼” (82.6mm) cut
height.
2. Route belts as shown.
Center Deck Belt Routing & Tensioning
Figure 6-15
9.3” – 10.3”
(236 – 262mm)
7.2” – 8.2”
(236 – 262mm)
