Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 21
PARAMETER DEFINITIONS
The parameters define all the options that are available to the operator of a
REFELX/SCANFLEX. It may be easier to read these in conjunction with the application
examples on Page 34 to 36.
Basic Set-up
NOTE:- (D=) factory default entry for that parameter.
Pr.1 Single or MultiPoint (D=1)
Enter 1 - Single point control
2 to 10 Multipoint control. This entry defines the number of points to be monitored
NOTE: Changing the entry in Pr.1 will cause all parameters to default to factory resets.
Pr.2 Transducer Type (Defined for each point) (D=1)
Enter 1 - Long range - RXM19/RXM19ER
2 - Short range - RXV15 Series
NOTE: Changing the entry in Pr.2 will automatically reset the default entries in Pr.4
to Pr.6, and all other POINT parameters will default to factory resets.
CONTROL parameters will not be changed.
For transducer specification see Page 48
Pr.3 Application/Units (Defined for each point) (D=2)
Enter 1 - Level Measurement - Feet
2 - Level Measurement - Metres To display in percent of span
3 - Distance Measurement - Feet set Pr.40 to 1.
4 - Distance Measurement - Metres
The system will be set to work in the specified units but the display can be made to display a
percentage, a converted value or a volume (Pr.40).
NOTE: Any subsequent change of units in Pr.3 (i.e. Pr.3 = 1-4) will reset parameters
Pr.4 to Pr.7 to new units and all other parameters will default to factory resets.
Pr.4 Empty Distance (Defined for each point) (D=30)
The distance from the transducer to the furthest point away, usually the bottom of the
vessel. Enter the distance in the units selected in Pr.3.
Note that this is not exactly at the transducer face.
Pr.5 Operational Span (Defined for each point) (D=30)
The distance between the furthest and nearest points over which measurement is
required. Enter the distance in the units selected in Pr.3.
