Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 31
Pr.71 Correction Value (Define for each point) (D=0.00)
Both negative and positive values can be input. This value must be entered in the
units selected at Pr.3.
This parameter has two uses:
1. It can be used to correct minor reading errors on the display
2. It can be used to prevent loss-of-echo when the target can go further
away from the transducer than the empty distance. Add the extra
depth to Pr.4 and enter minus the extra depth at Pr.71 in the units
selected at Pr.3
Pr.72 Decimal Display (D=2)
0 = No decimal places allowed.
1 = Up to 1 decimal place.
2 = Up to 2 decimal places.
3 = Up to 3 decimal places.
Pr. 73 Software Revision Number
Displays the revision number of the software, e.g. RE.XX
Pr.74 Reset Counter (D=0)
This count value gives the number of times that the system has been powered down or
reset since the last time the counter was zeroed. It is useful for checking if the power
supply is erratic.
Test Parameters
Pr.75 Digital Outputs (Applies to the point selected) (D=0)
To aid commissioning and the testing of external wiring, it is possible to define the
status of all five relays when in 'PROG' mode.
Press 'DSP' then:-
Enter 0 - To de-energise all relays
ADD 1 - To energise relay 1
ADD 2 - To energise relay 2
ADD 4 - To energise relay 3
ADD 8 - To energise relay 4
ADD 16 - To energise relay 5 - Applicable only to single point applications
e.g. To energise relays 2 and 5 enter '18'
The defined relay state will be maintained until over-written or until 'PROG' mode
times out (6 minutes). The time period can be extended by pressing a key during this
period to reset the time-out counter.
