Hycontrol REFLEX User Manual

Ref: REFLEX/SCANFLEX MANUAL
EDITION 1: JULY ’97 48
TRANSDUCER SPECIFICATION
MODEL BODY
MTRL
FACE
MTRL
FREQ
KHz
BEAM
ANGLE
INC
MAX.
RANGE
LIQS
MAX
RANGE
SOLIDS
TEMP
DEG C
*
HAZ.
AREA
PROTEC
-TION
WEIGHT
KG
MNTG PAGE
NO.
RXV15
RXT15
Xenoy Urethane 41.5 10 15m 6m -40 to +90 EExmIIT6 IP68 2.0 M20 50

RXV15T
Xenoy PTFE 41.5 10 13m - -40 to +90 EExmIIT6 IP68 3.0 Flange 50

RXV15P
Xenoy Poly-
ethy
lene
41.5 10 20m 15m -40 to +90 EExmIIT6 IP68 2.0 M20 50

RXM19
Poly-
propy-
lene
Poly-
ethy
lene
19 10 30m 25m -20 to +60 No IP68 2.8 M20 51

RXM19ER
Poly-
ethy-
lene
Poly-
ethy-
lene
17 5 50m 35m -20 to +60 No IP68 4.8 M20 52

* The RXV15 Series is Certified EExmIIT6 (Zone 1 and 2) for -20 to + 60ºC.
