SECTION 5.0 Hydro-Action
®
AP Series Plant Specifications.
Plant Capacities
Model
AP-500
LPA-
500
AP-600
AP-750
AP-
1000
AP-
1500
Design Flow (Gallons/Day)
500
500
600
750
1000
1500
CBOD
5
(Pounds/Day)
1.25
1.25
1.50
1.88
2.50
3.75
CBOD
5
(mg/l)
290
290
290
290
290
290
TSS (mg/l)
360
360
360
360
360
360
Hydraulic Capacity (Gallons)
Aeration Compartment
663
663
800
1002
1280
1895
Clarifier Compartment
173
173
219
273
352
518
Total Hydraulic Capacity
836
836
1019
1275
1632
2413
Hydraulic Retention Time
(Hours)
Aeration Compartment
32
32
31
29
29
25
Clarifier Compartment
8
8
9
9
8
8
Total Retention Time
40
40
40
38
37
33
Tank Dimensions
Diameter (in)
66
72
66
72
66
88
Height to Water Line (in)
64
46
64
64
70
82
Height with OPS Installed (in)
103.5
88
103.5
103.5
109
118
Compressor Usage
Rotary Compressor
1/4 HP
1/4 HP
1/4 HP
1/4 HP
3/4 HP
3/4 HP
Voltage (VAC)
115
115
115
115
115/120
115/120
Current (Amps)
3.9
3.9
3.9
3.9
7.8/3.9
7.8/3.9
Power (Watts)
120
120
120
120
120/560
120/560
Frequency (Hertz)
60
60
60
60
50
50
Flow (CFM)
4.3
4.3
4.3
4.3
8.2
8.2
Max Pressure (Psi)
5.0
5.0
5.0
5.0
7.0
7.0
Linear Compressor
HP80
HP80
HP100
HP120
HP150
HP200
Voltage (VAC)
120
120
120
120
120
120
Current (Amps)
0.059
0.59
1.55
2.1
2.1
1.75
Power (Watts)
71
71
186
252
252
210
Frequency (Hertz)
50
50
60
60
60
50
Flow (CFM)
2.9
2.9
4.5
4.5
4.5
8.2
Max Pressure (Psi)
5.0
5.0
5.0
5.0
7.0
7.0
