H3CR-F
Dimensions
Note: All units are in millimeters unless otherwise indicated.
66.6
0.7
17.4
52.3
6
5.7
R1.3
44.8 × 44.8
48
48
66.6
0.7
17.4
52.3
6
5.7
R1.3
44.8 × 44.8
48
48
37 dia.
14 dia.
37 dia.
14 dia.
11 pins
8 pins
H3CR-F
H3CR-FN
H3CR-F-300
H3CR-FN-300
H3CR-F8
H3CR-F8N
H3CR-F8-300
H3CR-F8N-300
103.2* 100.9
2.3
*
92.3* 90.0
2.3
*
80
17.4
17.4
75
81.5
81.5
*These dimensions vary with the kind of DIN track (reference value).
Y92F-30
P3GA-11
Y92F-30
P3G-08
Dimensions with Front Connecting Socket
P2CF-08-@/P2CF-11-@
H3CR-F
H3CR-FN
P2CF-11
P2CF-11-E
H3CR-F8
H3CR-F8N
P2CF-08
P2CF-08-E
Dimensions with Back Connecting Socket
P3G-08/P3GA-11
H3CR-F
H3CR-FN
H3CR-F8
H3CR-F8N
(When
Y92A-48G
mounted)
(When
Y92A-48G
mounted)
In the interest of product improvement, specifications are subject to change without notice.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
