Hydro Instruments GA-170 - Setup Mode Screens

9
FIGURE 5
Setup Channels
Ch1 Ch2 Ch3 Ch4
Display: PPM
Battery: No
Sensor 1 setup screens
Ch1Gas Type:
Cl2
Ch1 Decimal Posn:
XXX.X
Ch1 Full Scale:
10.0 PPM
Ch1 Zero Calibration:
0.0 PPM 0%
Ch1 Span Calibration:
5.0 PPM 50%
Ch1 Low Set:
1.0 PPM 10%
Ch1 High Set:
2.0 PPM 20%
Ch1 Alarm Delay:
10 secs
Ch1 Alarm Type:
Latch: 1 Fsafe: 0
GA-170 Setup Mode Screens
1
2
3
4
5
6
7
8
9
