Warning: Before attaching the electrode plugs please make
sure that they are free of corrosion. If not please replace them.
The plug must be pressed down onto the electrode as far as it
will go.
Note: Connect plugs to the correct electrodes. Note the color of
the knurled nut.
Note: Condensate connection must be showing in the front on
the left.
place cylinder vertically
into cylinder base
fix adapter with clip
push adapter onto
steam outlet
reconnect to power supply
