HygroMatik CompactLine - Water Drain

Page 58
* C01 C02 C06 C10 C17 C22 C30 C45 C58 Article No.
Description
18 8 12 12 12 18 18 18 24 36 E-3216022 Cylinder flange clamp
37 1 1 1 1 E-3220000 Cylinder base DN 20/25i/15/12
37 1 1 1 1 1 E-2206086 Cylinder base DN 40/25i/15/12
1 1 1 1 B-3216023 Mounting set for cylinder base
1 1 1 1 1 B-2214023 Mounting set for cylinder base
12 1 1 1 E-3216020 Condensate cap DN9
12 1 1 1 1 1 1 E-2204035 Condensate cap DN12
1 1 1 1 E-3221000 Adapter DN20/25 for Steam hose DN25
1 1 E-3221002 Adapter for steam hose DN25
1 1 E-3221008 Adapter for steam hose DN40, for SPA applications since 04.2010
1 1 E-2209000 Adapter for steam hose DN25
1 1 E-2209004 Adapter for steam hose DN40, for SPA applications since 04.2010
1 1 1 E-2209004 Adapter for steam hose DN40
1 1 E-2209006 Adapter for steam hose DN40
1 2 E-2209008 Adapter for steam hose DN40
1 E-2209014 Adapter steam outlet DN40/25
2 1 1 1 1 1 E-3221004 Clip for adapter DN25
2 1 1 1 2 E-2209002 Clip for adapter DN40
3 1 1 1 E-3216011 O-ring for adapter DN20/25
3 1 1 E-3221006 O-ring for adapter DN25
3 1 1 E-2204022 O-ring for adapter DN40, for SPA applications since 04.2010
3 1 1 2 E-2209010 O-ring for adapter DN25 (until October 2003)
3 1 1 1 2 E-2204022 O-ring for adapter DN40 (until October 2003)
1 B-3216081 maintenance kit for cylinder**
1 B-3216075 maintenance kit for cylinder**
1 B-3216077 maintenance kit for cylinder**
1 B-3216079 maintenance kit for cylinder**
1 B-2207081 maintenance kit for cylinder**, for SPA applications since 04.2010
1 B-2207029 maintenance kit for cylinder**
1 B-2207045 maintenance kit for cylinder**, for SPA applications since 04.2010
1 B-2207043 maintenance kit for cylinder**
1 B-2207031 maintenance kit for cylinder**
1 B-2207033 maintenance kit for cylinder**
1 B-2207035 maintenance kit for cylinder**
Water feed
21
0,7 0,7 0,8 0,9 0,9 0,9 0,9 0,9 1,6
E-2604002 Connecting hose, solenoid valve - cylinder base, per m
25 1 1 1 B-2304081 Solenoid valve, servo controlled, straight type, 0,2 - 10bar, 1,2 l/min
25 1 B-2304083 Solenoid valve, servo controlled, straight type, 0,2 - 10bar, 2,5 l/min
25 1 1 1 1 1 B-2304085 Solenoid valve, servo controlled, straight type, 0,2 - 10bar, 3,3 l/min
1 1 1 B-2304059 Double solenoid valve for Super flush applications, 2.5l/min
1 B-2304061 Double solenoid valve for Super flush applications, 2.5l/min
1 1 1 1 1 B-2304069
Double solenoid valve for Super flush applications, 3.5l/min
1 1 1 1 1 1 1 1 1 E-2304036 Sealing for solenoid valve/unit
56 1 1 1 1 1 1 1 1 1 B-2304031 Hose for water connection, 3/4" cap nuts on both sides
38
0,4
0,4
0,4 0,4 0,6 0,6 0,6 0,6 0,8
E-2604004 Hose for manual water drain
1 1 1 1 1 1 1 1 1 E-2305002 Sealing for hose for water connection
20 1 1 1 1 1 1 1 1 1 E-2604062 Stopper, conical, lock for hose
22 4 4 4 4 4 4 4 4 4 E-2304015 Hose clamp 10-16mm
24
0,1 0,1 0,1 0,1 0,1 0,1 0,1 0,1 0,1
E-2604002 Connecting hose solenoid valve - bush for earthing
23 1 1 1 1 1 1 1 1 1 E-2304080 Bush for earthing
58 1 1 1 1 1 1 1 1 1 E-2604094 double check valve
Water drain
1
B-3401005 Pump-drain-hose-system (Pos. 6, 14, 15, 30, 31)
1
B-3401007 Pump-drain-hose-system (Pos. 6, 14, 15, 30, 31)
1 B-3401015 Pump-drain-hose-system (Pos. 6, 14, 15, 30, 31)
1 B-3401017 Pump-drain-hose-system (Pos. 6, 14, 15, 30, 31)
1 1 1 B-3401019 Pump-drain-hose-system (Pos. 6, 14, 15, 30, 31)
1 B-3401013 Pump-drain-hose-system (Pos. 6, 14, 15, 30, 31)
1 B-3401021 Pump-drain-hose-system (Pos. 6, 14, 15, 30, 31)
