HygroMatik CompactLine - Cable Connections

Page 39
MiniSteam:
DBE:
7.2 Cable Connections
The table below shows the cable connections provided in elec-
trode steam humidifiers:
Characteristics of metric cable connections:
Type Power Usage Circuit Protection
MS5, 230V/1/N 15,7 A 1 x 16 A
MS5, 400V/3/N 5,4 A 3 x 6 A
MS10, 400V/3/N 10,8 A 3 x 16 A
Type Power Usage Circuit Protection
DBE1 3,3 A 1 x 6 A
DBE2 6,5 A 1 x 10 A
DBE6 6,5 A 3 x 10 A
DBE10 10,8 A 3 x 16 A
DBE17 18,4 A 3 x 25 A
DBE30 32,5 A 3 x 35 A
DBE45 48,8 A 3 x 63 A
Unit Connection
M16
Connection
M25
Connection
M32
HY05, HY08 4 3 -
HY13, HY17,
HY23, HY30,
Hy45
421
HY60, HY90,
HY116
-42
C01, C02 4 1 -
C06 3 2 -
C10 3 3 -
C17, C30 4 3 -
C45, C58 4 2 1
MS5, MS10 - 2 -
Thread
across-flats
dimensions [mm]
for cable diameter
[mm]
M16x1,5 19 4,5 - 10
M25x1,5 30 9 - 17
M32x1,5 36 11 - 21
