13. Technical Data
Technical Data Steam Humidifiers CompactLine C01-C58
Type C01 C02 C6 C10 C17 C22 C30 C45 C58
Steam Output [kg/h] 1,0 2,0 6,0 10,0 17,0 22 30,0 45,0 58,0
Electrical Supply* 230V/1~/N
50-60Hz
400V/3~/N 50-60 Hz
Electrical Power [kW] 0,75 1,5 4,5 7,5 12,8 16,5 22,5 33,8 43,5
Current [A] 3,3 6,5 6,5 10,8 18,4 23,8 32,5 48,8 62,8
Fuse [A]**** 1x6 1x10 3x10 3x16 3x20 3x35 3x35 3x63 3x63
Control Type Basic, Comfort, Comfort Plus
Control Voltage 230V
Steam Hose Connection [mm] 1x25 1x25 1x25 1x25 1x25 1x40 1x40 1x40** 2x40
Condensate Hose Connection [mm] 1x9 1x9 1x9 1x12 1x12 1x12 1x12 1x12*** 2x12
Empty Weight [kg] 9 101012191920 22 31
Operational Weight [kg] 11 13 13 18 37 37 38 49 77
Dimensions***** Height [mm] 370 350 438 480 653 653 653 707 790
Width [mm] 355 392 401 414 480 480 480 527 615
Depth [mm] 171 221 187 217 283 283 283 325 392
Water Supply
100 x 10
3
til 100 x 10
4
Pascal, for ¾" external thread
Fan Unit, wallmounted - - VG08 VG17 VG17 VG30 VG30 2 x VG30 2 x VG30
Air Circulation of Fan Unit [m³/h] - - 160 185 185 350 350 2 x 350 2 x 350
Technical Data Steam Humidifiers for SPA
CompactLine C01..-DS - C58..-DS
Type
C01 C02 C6 C10 C17 C22 C30 C45 C58
Steam Output [kg/h] 1,0 2,0 6,0 10,0 17,0 22 30,0 45,0 58,0
Electrical Supply* 230V/1~/N
50-60Hz
400V/3~/N 50-60 Hz
Electrical Power [kW] 0,75 1,5 4,5 7,5 12,8 16,5 22,5 33,8 43,5
Current [A] 3,3 6,5 6,5 10,8 18,4 23,8 32,5 48,8 62,8
Fuse [A]**** 1x6 1x10 3x10 3x16 3x20 3x35 3x35 3x63 3x63
Control Type Basic-DS, Comfort-DS, Comfort Plus-DS
Control Voltage 230V
Steam Hose Connection [mm] 1x25 1x25 1x25 1x40 1x40 1x40 1x40 1x40** 2x40
Condensate Hose Connection [mm] 1x9 1x9 1x9 1x12 1x12 1x12 1x12 1x12*** 2x12
Empty Weight [kg] 9 101012191920 22 31
Operational Weight [kg] 11 13 13 18 37 37 38 49 77
Dimensions***** Height [mm] 370 350 438 480 653 653 653 707 790
Width [mm] 355 392 401 414 480 480 480 527 615
Depth [mm] 171 221 187 217 283 283 283 325 392
Water Supply
100 x 10
3
til 100 x 10
4
Pascal, for ¾" external thread
***** Outer dimensions of width and depth. Height incl. drain connection.
**** Times 1.3 power input after Full Blow Down. If expulsion fuses are used close to their specific limit we recommend to choose expulsion fuses
with a higher range.
*** The delivery includes T-pieces to condensate return of two manifolds.
** The delivery includes required T-pieces for connection of two manifolds.
* Other voltages on request.
