9. Reinstall the mass air flow sensor side of the air intake duct.
To install the throttle body side of the duct, use the flathead
screwdriver to secure the lower side of the duct onto the
underside of the throttle body, then work the sides and the top
of the duct onto the throttle body assembly.
10. Tighten the hose clamp using the flathead screwdriver.
11. Reconnect the intake air temperature sensor connector.
12. Start the vehicle and allow it to warm up to normal operating
temperature.
13. Check the coolant level in the radiator overflow/fill reservoir
and fill as needed.
5
Figure A
Throttle
body
Thermostat
housing
Pressure side
bleed screw
Mass air
flow sensor
CAMARO/FIREBIRD/IMPALA SS/CAPRICE/
ROADMASTER POWERSTAT INSTALLATION
CORVETTE POWERSTAT INSTALLATION
Figure B
Throttle
body
Thermostat
housing
Mass air
flow sensor
Pressure side
bleed screw
