POWERMAX65/85 SERIAL COMMUNICATION PROTOCOL
Command Name Register
(Hex)
Description
cut_mode_force
Scaling is 16-bit, fixed-
point binary with 1-bit sign
at MSB and 0-bit decimal
at LSB.
0x2093 Sets the cut mode to one of these values:
Normal = 1
CPA = 2
Gouge = 3
cut_mode_force value :01062093xxxxcc
where xxxx equals the cut mode value
cc equals LRC (checksum)
Samples:
Normal :010620930001450D0A
Response: :01062093000145
CPA :010620930002440D0A
Response: :01062093000244
Gouge :010620930003430D0A
Response: :01062093000343
Sample ModBus Command String Tables
The following tables show sample command strings that could be sent from the CNC and the responses from the power
supply. The sample command strings show a single register write function. While the ModBus protocol allows you to
write to and read multiple registers, these functions are not shown in the samples.
