Hypontech HHT-12000 Series User Manual

HHT-5000/6000/8000/10000/12000 USER MANUAL 12
3
M6×12 pan head screw
PE Conductor cross-section: 16 mm²
6. COMMISSIONING
5.1 Safety Instructions
1. Measure the frequency and voltage of grid connection and make sure they follow the
inverter’s grid connection specifications.
2. An external circuit-breaker on the AC side (or a fuse) at 1.25*AC rated current is
strongly recommended.
3. Reliability of all earth connections must be tested and valid.
4. Before commissioning, disconnect the inverter and the circuit-breaker or fuse, and
prevent accidental reconnection.
The cable specification is shown as below:
No
Item
Type
Specification
1
PE cable
Outdoor copper
cable
 Conductor cross-section: 16mm²
2
AC Output
cable
Outdoor copper
cable
 Diameter:12~24mm
 Cable outer diameter:5K:2.5~12 mm²
6~8K:6~16 mm²; 10~12K:10~25
mm²
BACK-UP
Output
cable
Outdoor copper
cable
 Diameter:12~24mm
 Cable outer diameter:5K:2.5~12 mm²
 6~8K:6~16 mm²; 10~12K:10~25
mm²
3
DC Input
cable
Standard outdoor
PV cable PV1-F
Model
recommended
 Conductor cross-section: 2.5~6 mm²
 Cable outer diameter:5~8mm
Battery
Input cable
Standard outdoor
PV cable PV1-F
 Conductor cross-section: 6 mm²
 Cable outer diameter:8mm
