10 Technical Data
10.1 Electrical data
Model HPS-
3680
HPS-
4000
HPS-
5000
HPS-
6000
HPS-
6500
Input(DC)
Max. PV powerWp)
5152 6160 7000 7800 8125
Max. input voltage(V) 600 600
MPP voltage range(V) 80-520 80-550
Min. input voltage(V) 70 70
Nominal DC-Input
voltage(V)
360 360
Max input current(A) 12/12 12/12
Max short DC
current(A)
15/15 15/15
No. of independent
MPPT inputs
2 2
No. of PV strings per
MPPT
1 1
Output(AC)
Rated Power(W) 3680 4000 5000 6000 6500
Max. apparent AC
power(VA)
3680 4400 5000 6000 6600
Rated grid
voltage(Vac)
220/230/240 220/230/240
Rated power
frequency(HZ)
50/60 50/60
Max. output
current(A)
16 20 23 27.3 29.6
Adjustable
displacement power
factor
0.8ind to 0.8cap 0.8ind to 0.8cap
