• Adjust Tool Parameters – Select the desired configuration including Torque and Fastener and optionally
Angle and Release.
• Rundown – Thread the nut onto the stud until positioned tight against the flange. When using the tool to run down the
nut set the speed control to “RUNDOWN” and position the tool on the nut – pull the trigger to quickly run down the nut
until it touches against the flange. When finished, set the speed control switch to TORQUE.
• Position Back Wrench - If needed, apply a back wrench to the back nut on the bolt to prevent it from turning during
tightening. If using the HYTORC Back Washer a back wrench is unnecessary.
• Position Drive/Socket - Place socket over nut until firmly engaged. If using the HYTORC Washer or HYTORC Nut, make
sure the driver properly engages the fastener.
• Position Reaction Arm - If a reaction arm is used, make sure it is firmly abutted against a stationary object (e.g. an
adjacent nut, flange, equipment housing etc.).
BASIC BOLTING SETUP
(CONT’D.)(CONT’D.)
