ENG- usermanual MXT-XLT.docx Version 2.5 / Jan-16 14
ITEM
QTY.
DESCRIPTION
MXT-.7
MXT-1
MXT-3
MXT-5
MXT-10
1
1
Housing (with end cap, shroud, access plug and seal kit)
MXT-.7-01
MXT-01 -01
MXT-03-01
MXT-05-01
MXT-10-01
3
1
Rear Reaction Arm Assembly
MXT-.7-03
MXT-01-03
MXT-03-03
MXT-05-03
MXT-10-03
4
2
Drive Plate Universal
MXT-.7-04
XLT-01-04
XLT-03-04
XLT-05-04
XLT-10-04
5
1
Sq Drive Assembly
MXT-.7-05
XLT-01-05-1
XLT-03-05-1
XLT-05-05-1
XLT-10-05-1
6
1
Ratchet
MXT-.7-06
XLT-01-06-1
XLT-03-06-1
XLT-05-06-1
XLT-10-06-1
7
2
Sq Drive Bushing
MXT-.7-07
XLT-01-07-1
XLT-03-07-1
XLT-05-07-1
XLT-10-07-I
8
2
Drive Sleeve Spline
MXT-.7-08
XLT-01-08-1
XLT-03-08-1
XLT-05-08-1
XLT-10-08-1
10
1
Reaction Pawl Assembly
MXT-.7-10
MXT-01-10
MXT-03-10
MXT-05-10
MXT-10-10
11
1
Drive Retainer Assembly
MXT-.7-11
XLT-01-11
XLT-03-11
XLT-05-11
MXT-10-11
13
1
Drive Plate Roll Pin
MXT-.7-13
XLT-01-13
XLT-03-13
XLT-05-13
XLT-10-13
14
1
Left and Right Lever Assembly
MXT-.7-14
MXT-01-14
MXT-03-14
MXT-05-14
MXT-10-14
18
1
Reaction Pawl Spring
MXT-.7-18
MXT-01-18
MXT-03-18
MXT-05-18
MXT-10-18
19
1
Rod End Pin
MXT-.7-19
XLT-01-19
XLT-03-19
XLT-05-19
XLT-10-19
26
1
End Cap
MXT-.7-26
MXT-01-26
MXT-03-26
MXT-05-26
MXT-10-26
27
2
Drive Pawl Spring
MXT-.7-27
XLT-01-27
XLT-03-27
XLT-05-27
XLT-10-27
28
1
Reaction Arm Lever Assembly
MXT-.7-28
MXT-01-28
MXT-03-28
MXT-05-28
MXT-10-28
30
2
Drive Sleeve Retaining Ring
MXT-.7-30
XLT-01-30
XLT-03-30
XLT-05-30
XLT-10-30
31
1
Shroud
MXT-.7-31
MXT-01-31
MXT-03-31
MXT-05-31
MXT-10-31
32
2
Shroud Screw
MXT-.7-32
XLT-01-32
MXT-03-32
MXT-03-32
XLT-10-32
33
1
Drive Pawl Spring Secondary
n/a
n/a
n/a
n/a
n/a
34
1
Reaction Arm Thrust Plate
MXT-.7-367
MXT-01-367
MXT-03-367
MXT-05-367
MXT-10-367
37
2
Thrust Plate Screw
MXT-.7-503
MXT-01-503
MXT-03-503
MXT-05-503
MXT-10-503
39
1
Catch Lever, Reaction Arm
MXT-.7-328
MXT-01-328
MXT-03-328
MXT-05-328
MXT-10-328
38
1
Reaction Arm Lever Spring
MXT-.7-508
MXT-01-508
MXT-03-508
MXT-05-508
MXT-10-508
40
1
Roll Pin Drive Pawl Primary
MXT-.7-40
XLT-01-40
XLT-03-40
XLT-05-40
XLT-10-40
41
1
Roll Pin Drive Pawl Secondary
MXT-.7-41
XLT-01-41
XLT-03-41
XLT-05-41
XLT-10-41
42
1
Roll Pin Reaction Pawl
MXT-.7-42
XLT-01-42
XLT-03-42
XLT-05-42
XLT-10-42
43
1
Reactin Arm Boot
MXT-.7-43
XLT-01-43
XLT-03-43
XLT-05-43
XLT-10-43
44
2
Reaction Arm Boot Pin
MXT-.7-44
MXT-01-44
MXT-03-44
MXT-05-44
MXT-10-44
45
1
Reaction Arm Lever Pin
MXT-.7-509
MXT-01-509
MXT-03-509
MXT-05-509
MXT-10-509
46
1
Serial Plate Right/Left Set
MXT-.7-46
MXT-01-46
MXT-03-46
MXT-05-46
MXT-10-46
48
2
Access Plug (with 0 ring)
MXT-.7-02
MXT-01-02
MXT-03-02
MXT-05-02
MXT-10-02
58
1
Shroud Spring Screw
MXT-.7-58
XLT-01-58
XLT-03-58
XLT-05-58
XLT-10-58
59
1
Shroud Spring
MXT-.7-59
XLT-01-59
XLT-03-59
XLT-05-59
XLT-10-59
61
1
Piston Assembly
MXT-.7-61
XLT-01-61
XLT-03-61
XLT-05-61
XLT-10-61
63
1
Drive Pawl Assembly
MXT-.7-63
XLT-01-63
XLT-03-63
XLT-05-63
XLT-10-63
1
1
Uniswivel Assembly
MXT-001ACL
MXT-001ACL
MXT-003ACL
MXT-003ACL
MXT-010ACL
Model 1 & 3 refer to the 1st letter of serial # to determine A or D style
MXT-001CL
MXT-001CL
MXT-003CL
MXT-003CL
MXT-010ACL
001A
1
Male Coupler (comes with nipple)
090155-1/8
090155-1/8
090155-1/4
090155-1/4
090155-1/4
001B
1
Female Coupler
090156-1
090156-1
90156
90156
90156
001C
1
Uniswivel Seal Kit
MXT-001-00
MXT-001-00
MXT-003-00
MXT-003-00
MXT-010-00
1
Housing Seal Kit
MXT-.7-62
MXT-01-62
MXT-03-62
MXT-05-62
MXT-10-62
1
Maintenance Kit
MK-HY-.7MXT
MK-HY-1MXT
MK-HY-3MXT
MK -HY-5MXT
MK-HY-10MXT
