i-team i-mop Lite - Operation: Filling and Moving; Filling the cleaning solution tank; Moving to the job site

22
6.1.2 Fill the cleaning solution tank
1. Remove the stopper.
2. Pour in a maximum of 0.79 gal/ 3 L of
cleaning fluid.
3. Replace stopper and make sure it seals tight.
4. Put the i-mop® Lite in park position (see 4.2).
5. Put the tank on the i-mop Lite with the valve
first (Figure 14, pos 1).
6. Press the tank downward to break the valve
seal.
7. Push the tank in place, the magnet will lock
the solution tank in place.
8. Clean your hands afterwards.
6.2 Operation procedure
6.2.1 Walking to the job site
Figure 15
To move the i-mop Lite from one location to another one in a building:
Figure 14
