● Status LED Displays of EtherNet/IP Type { : Illuminating, × : OFF, ☆ : Flashing
Name Indication Color Description
×
Power is OFF or IP addresses are not set
{ (GN)
Connection is established and the communication under normal condition.
☆ (GN)
Online but network connection is not yet established. Communication Stop (Network
is normal). Check the conditions of master unit.
{ (RD)
Communication Error. Communication
cannot be established due to the error
detection such as IP address duplication.
NS
☆ (RD)
Communication Error. (Communication
Time-out Detection)
Check the conditions of IP address
settings, communication line, the power
of hub units, noise prevention, etc.
×
Power OFF
{ (GN)
The machine is in the normal operation.
The machine is under the control of the scanner (master)
☆ (GN)
The connection with the scanner (master) is not established.
Check the construction information settings.
Check if the scanner (master) is in the idle condition.
{ (RD)
Hardware Error.
The replacement of the board is required. Please contact us.
MS
☆ (RD)
There is an error occurred but is not critical such like a user setting error or
configuration error.
It can be recovered with a rebuild of the settings.
● Status LED Displays of PROFINET-IO Type { : Illuminating, × : OFF, ☆ : Flashing
Name Indication Color Description
×
The power is OFF or there is no connectable controller.
{ (GN)
Connection is established, communication in normal condition (RUN status)
NS
☆ (GN)
Connection is established, but communication in pause (STOP status: network is in
normal condition)
×
Power OFF
{ (GN)
The machine is in the normal operation.
☆ (GN)
In diagnosis of communication system.
{ (OR)
There is a hardware error (in EXCEPTION condition).
The replacement of the board is required. Please contact us.
MS
☆ (RD)
There is an error in communication setting, IP address or station name setting.
When an error occurs, connect the teaching tool such as PC software or teaching pendant and check it
using the status monitor.
All the alarms for the fieldbus related are described as follows. For other alarms, refer to the instruction
manual for the controller body and remedy it.
Code Error Name
ID
(*1)
RES
(*2)
Cause/Treatment
0F2
Fieldbus
Module Error
05
×
Cause : An error is detected on Fieldbus module (circuit component)
Treatment
: Check the parameter.
0F3
Undetected
Fieldbus
Module Error
04
×
Cause : Fieldbus module (circuit component) cannot be detected
Treatment
: Turn ON the power again. If the error is not removed, contact
our company.
(*1) ID → Simple Alarm Code
(*2) RES → Alarm Reset Available/Unavailable ○ : Alarm Reset Available/× : Alarm Reset Unavailable
