IAME Parilla Leopard RL - Install the Intake Silencer

MAN048ING20
3.8.17 PLACE THE WIRING HARNESS
BATTERY TERMINALS UNDER THE
BATTERYSTRAP(SEEFIG.36).
SUGGESTION:
NEVER CONNECT THE BATTERY UNTIL
YOU ARE READY TO START THE ENGINE.
SEAL THE BATTERY TERMINALS WITH
PLASTICTAPETOAVOIDTHATEVENT UAL
VIBRATIONS MIGHT DISCONN ECT THE
TERMINALS.
3.8.18 SCREW THE SPARK CAP ON THE
H.T.COIL(SEEFIG.37).
3.8.19 FIX THE CAP TO THE H.T. CABLE
WITHAPLASTICCLAMP(SEEFIG.38).
· INSTALLTHESPARKPLUG.
TORQUEAT20÷26Nm(175÷230 inlb)
· INSTALL THE CAP ON THE SPARK
PLUG.
3.9 INSTALLTHEINTAKESILENCER
MAKE SURE THAT THE FILTER HAS THE
INLETHOLESTOWARDSTHEUPPERSIDE.
FIX THE FILTER ON THE CARB. WITH A
STEEL CLAMP AND THE FILTER TO THE
CHASSIS SIDE RAILS WITH PLASTIC
CLAMPS(SEEFIG.39).
Fig.36
Fig.37
Fig.38
Fig.39
